OVERVIEW
- measuring ranges up to 0…40 bar
- housing diameter 80 mm
- stainless steel casing
- particularly solid construction
- shock and vibration resistance
- for gaseous and liquid media that are not viscous and crystallising
- application: hydraulics, compressors, refrigeration technology
General Specifications
| Design |
EN837-1
|
| Measurement range |
0...40bar
|
| Process connection |
G3/8B
|
| Housing dimensions |
Ø80mm
|
| Measuring element |
Bourdon tube type "C", copper alloy
Bourdon tube type "C", stainless steel
|
| Accuracy |
±1.6%
|
| Filling |
lack
|
| Operating temperature |
-40...+60°C
|
| Medium temperature |
max 200°C
max. 65°C
|
| Degree of protection |
IP54
|
| Housing material |
stainless steel
|
| Installation |
rear central connection
bottom connection
|
