Overview
- stainless steel sensor (welded)
- nominal pressure: 0...6 bar up to 0...60 bar / -1...6 bar up to -1...60 bar
- accuracy: 0.5% FSO
- areas of application: refrigeration
Description
CCE-17.600G pressure transmitters have been designed to work in harsh conditions. Equipped with a stainless steel sensor, they guarantee a measurement accuracy of 0.5% in accordance with the IEC 60770 standard. The nominal pressure range for the CCE-17.600G is 6 ... 600 bar. The transmitters are ideally suited for applications in mechanical and refrigeration engineering, medical technology, commercial vehicles and mobile hydraulics.
Specification
| Measurement range |
0...6 bar up to 0...60 bar
|
| Output type |
4...20 mA, 2-wire
10…90% Vs, 3-wire ratiometric
0...10V, 3-wire
|
| Process connection |
G 1/2
G 1/4
1/2 NPT
1/4 NPT
|
| Electrical connection |
connector M12x1
cable outlet
ISO 4400
|
| Diaphragm |
stainless steel
|
| Power supply |
2.7...5V DC (3-wire ratiometric)
8...32V DC
14...30V DC
|
| Accuracy |
±0,5%
|
| Operating temperature |
-40...+85°C
|
| Medium temperature |
-40...+125°C
|
| Protection class |
IP 65
IP 67
|
| Case material |
stainless steel
|
