Description
- Turnable display with backlight
- Data interface RS-232 as standard
- Delivered in a robust carrying case
- Selectable measuring units: N, kN, kgf, tf
- Peak-Hold function to capture the peak value or Track function for continuous display of measurement
- Measuring with tolerance range (limit-setting function): Upper and lower limit adjustable, in pull and push direction. The process is supported by an audible and visual signal
- Auto-Power-Off
- Internal memory for up to 10 measurement values
Technical Data
| Measuring range force [Max] (N) | 5 kN |
| Readability force [d] (N) | 1 N |
| Tolerance (% of [Max]) | 0,5% |
| Measuring head measuring frequency | 2 kHz |
| Number of platforms / channels | 1 |
| Supplied power supply | Accu & Power supply |
| Rechargeable battery | 8,4V / 1200mAh Ni-Hi |
| Memory function | |
| Statistic function | |
| Limit-setting function | |
| Hold function | |
| Peak function | |
| Dimensions completely mounted (W×D×H) | 320×190×166 mm |
| Net weight approx. | 1,8 kg |
| Interfaces | RS-232 standard |
| Cable length | 3 m |
| GTIN/EAN number | 4045761140653 |
