Description
- High precision (comprehensive error 0,5% F.S.)
- RoHS compliant
- Area of application: Compressive force measurements
- Suitable for weight measurement as well as force and force test stands
Technical Data
Weighing capacity [Max] 5 kg Measuring range force [Max] (N) 50 N Design Load cell Directions of force compression Measuring applications force, mass Load cell - Combined error 0,5% Load cell OIML class G5 Load cell - characteristic value - nominal 1 mV/V IP protection - complete device IP67 Material steel, stainless Load cell connection 4-wire Cable length 2 m Mounting - force application Thrust piece (from customer side) Mounting - force dissipation Mold nest
