Description
- Backlit graphic display, digit height 14 mm
[[1]] Active drying process
[[2]] Active heating profile
[[3]] Active switch-off criteria
[[4]] Previous drying time
[[5]] Current temperature
[[6]] Current moisture content in % - Infrared heater 400 W
- Suitable for temperature-insensitive samples
- Observation window above the sample, useful during initial setting
- Internal memory for automatic sequence of 15 complete drying processes and 5 drying processes carried out
- The last value measured remains on the display until it is replaced by a new measurement
- 50 sample plates included
- Application handbook: In the download centre you will find a practical application handbook containing many examples, field reports, settings and tips for each KERN moisture analyser
Technical Data
Weighing capacity [Max] 110 g Readability [d] 0,001 g Weighing system Strain gauge Sample – Moisture content 20% - 100% Sample – Dry content 100% - 20% Temperature [Min] (°C) 40 °C Temperature [Max] (°C) 160 °C Stabilization time 3 s Units g, % Humidity, % Dry mass Reproducibility 0,001 g Linearity ± 0,003 g Readability moisture [d] (%) 0,01% Drying modes Standard drying, Rapid drying, Gentle drying Switch-off criteria time controlled, automatic, manual Input voltage device / power [Max] 230 V AC, 50 Hz GTIN/EAN number 4045761226319
