Description
- Internal automatic adjustment, guarantees high accuracy and makes it independent of location. Ideal for applications requiring legal metrology
- High-quality tuning fork weighing system for fast display of the weighing value, precise dosing and high mechanical robustness
- Capacity display : A rising bar graph display shows the remaining available weighing range
- Accurate counting: Automatic reference optimization gradually improves the average value of the part weight
- Compact dimensions, advantageous in limited space conditions
- Large, shock-resistant stainless steel weighing plate
- Large glass draft shield with 3 sliding doors for convenient access to the weighing goods, weighing chamber W×D×H 172×171×160 mm
- Protective work cover included in delivery
Functions
Percentage determination ✓
Tolerance weighing ✓
Tolerance weighing - type of signal visual
Capacity - Display ✓
Counting function ✓
Counting resolution (laboratory conditions) 620.000
Counting reference weight can be entered ✓
Smallest piece weight when piece counting - laboratory conditions 1 mg
Smallest piece weight when piece counting - normal conditions 10 mg
Reference quantity 10, 30, 50, 100
IP protection - display no IP protection
IP protection - platform no IP protection
Technical data
| weighing range [Max] | 620 g |
| readability [d] | 0.001 g |
| calibration value [e] | 0.01 g |
| units | g, gn, dwt, tl (Tw), tl (HK), ozt, tl (Singap, Malaysian), ct, mo, lb, oz, tol |
| Conformity assessment possible ex works | |
| minimum load [Min] | 0.02 g |
| linearity | ± 0.004 g |
| reproducibility | 0.001 g |
| settling time | 3 s |
| tolerance weighing | |
| interfaces | RS-232 as standard |
| adjustment options | Adjustment with internal weight (automatic) |
| ambient temperature range | 5 °C – 40 °C |
| Dimensions weighing surface (Ø) | 140 mm |
| Material Windshield | Glass |
| Housing material | plastic |
| Housing dimensions (W×D×H) | 196×293×266 mm |
| material weighing plate | stainless steel |
| Net weight approx. | 4.2 kg |
| design of the scale | single-range scale |
| GTIN/EAN number | 4045761179882 |
Files
| Data sheet | |
| Manual EN |
PNJ 600-3M |
