Description
TRS-01a is designed particularly for multipoint temperature and humidity measurement systems to measure temperature in rooms where food products are manufactured and stored. It is equipped with RS-485 / Modus RTU communication interface. Measures temperature within the range of -40°C to +85°C. Has a small plastic casing.
Specification
| Number of inputs |
1
|
| Input type |
integrated temperature probe (semiconductor integrated circuit)
|
| Input range |
temperature: -40...+85°C
|
| Output type |
no output
|
| Power supply |
9...12V DC
|
| Display |
no display
|
| Communication Interface |
RS-485 / Modbus RTU
|
| Transmission parameters |
9600 bit/s, 8N1
|
| Operating temperature |
-40...+85°C
|
| Protection class |
IP 40
IP 65
|
| Case material |
ABS
|
| Mounting |
wall
|
| Case dimensions |
64 x 58 x 35 mm
|
